Continuing work on my research lab design, I wanted to generate floor plans that were a little more informational than the standard line drawings. Therefore, I turned the floor plans into oblique projection drawings using my Sketchup model and a technique described many years ago seen here. Using this method, the plans do not distort allowing one to still measure off of them and put to scale. However, unlike 2d floor plans, these have a three dimensional feel to them allowing for more articulation of wall materials and tectonics. Below is a quick break down of the illustration.
1. Compile Base Images and Renderings
Sketchup Line Work
V-Ray Ambient Occlusion Rendering
V-Ray Clay Rendering
Three Layers Combined
I used three base images to compile the bulk of the illustration. I used a line work export from Sketchup, an ambient occlusion rendering from V-Ray, and a clay rendering from V-Ray. I then combined them in Sketchup to get the above image. The line work and AO pass add detail that help articulate what is happening with the geometry. Since I am going for more of a diagrammatic image, I leaned on these passes more than the clay rendering.
2. Poche
The focus of this illustration is to describe the floor plan design. Therefore, I want to play up the cut of the section. To do this, I painted the section cut in Photoshop with black paint.
3. Extra Details
I ended up painting the floor a dark grey to create more of a contrast between it and the walls. I also abstractly introduced sticks representing trees to give a some texture to the illustration.
4. Stretch
At this point, I stretched the image to make it a plan oblique before I add text. Again, the process of creating a plan oblique image from a Sketchup model can be seen here.
5. Annotation and Final Coloring
Finally, I dropped in some annotation and did some quick color editing using Topaz. I expect coloring may change again once I start developing final page spreads for the project.
Another masterpiece, as always! How do you do to preserve the transparence in vray clay render mode? And, at last, how do you export the ambient occlusion? Thanks’ Alex. Sorry for my bad English ?
To preserve transparency, you have to uncheck the box “can be overridden” for the material in the V-Ray material editor. For AO, there are some tutorials that describe how to set it up on Youtube. The process is too long for me to explain here.
nice as always! how did you do the vegetation.. is it photoshopped,rendered or painted? can you explain it a bit …..
thanks alex
The vegetation on top is cute. 🙂
They vegetation was all Photoshop. It is made up of several aerial images of vegetable fields that I found online.
What method did you use to cut the model for the Vray rendering, since Vray for Sketchup does not allow you to render a “live” Sketchup section plane cut. I’ve used Zorro and other plug-ins in the past or simply explode the model and intersect the selection with a plane at the cut height you want and delete everything above. This always seems to be a messy venture for me and I was curious how you prefer to do this. Thanks.
For now, I use the Zorro plugin. However, it sounds like the new version of V-Ray for Sketchup will support rendering a Sketchup section cut when it is released. Fingers crossed.
